CW61160×6000mm Used Heavy Duty Lathe Machine
| Item | Specification |
|---|---|
| Model | CW61160 ×6000mm |
| Max Swing over Bed | 1600 mm |
| Max Swing over Carriage | 1250 mm |
| Max Workpiece Length | 6000 mm |
| Spindle Bore | 130 mm |
| Main Motor Power | 22 kW |
| Spindle Speed Range | 2-630 rpm, 21-speed |
| Net Weight | 18000 kg |
| Year | 2013 |
| Machine Condition | 85% new |
| Overall Dimension(L×W×H) | 8500 ×2100 ×2200 mm |
| Condition | Used, tested, good working condition |
| Item | Specification |
|---|---|
| Model | CW61160 ×6000mm |
| Max Swing over Bed | 1600 mm |
| Max Swing over Carriage | 1250 mm |
| Max Workpiece Length | 6000 mm |
| Spindle Bore | 130 mm |
| Main Motor Power | 22 kW |
| Spindle Speed Range | 2-630 rpm, 21-speed |
| Net Weight | 18000 kg |
| Manufacturing Year | 2013 |
| Machine Condition | 85% new |
| Overall Dimension(L×W×H) | 8500 ×2100 ×2200 mm |
| Machine Status | Used, fully tested, good working condition |
Advantages
- Super heavy-duty horizontal lathe with ultra-thick cast iron bed, excellent rigidity for heavy stock removal.
- Well-maintained guideway and spindle assembly, stable machining accuracy for large & oversized workpieces.
- Wide spindle speed range, widely used for large rollers, big shafts, heavy flanges and mining equipment parts.
- Standard accessories included, ready for production after on-site installation.
- Strict inspection before delivery, support video inspection and factory on-site visit.
- Cost-effective second-hand heavy lathe, ideal solution for large-scale heavy metal turning.
